The 485nm Narrow Bandpass Filter is a precision optical filter
designed to transmit light around the 485nm center wavelength
while effectively suppressing unwanted out-of-band light.
With a10nm FWHM bandwidthandOD5 blocking performance,
this optical filter provides high spectral selectivity for optical
systems requiring accurate wavelength discrimination and strong background-light suppression.
The filter uses a high-qualityoptical glass substrate with
multilayer optical coating, providing stable optical performance and reliable long-term operation.
An optionalmetal mounting frameis available for convenient installation
and mechanical protection, making the filter suitable for integration
into optical instruments and imaging systems.
| Parameter | Specification |
|---|---|
| Center Wavelength | 485nm |
| FWHM | 10nm |
| Optical Density | OD5 |
| Substrate | Optical Glass |
| Coating | Multi-layer Optical Coating |
| Transmission | High Transmission at Center Wavelength |
| Blocking Range | UV–NIR, Customized |
| Shape | Round / Square / Custom |
| Mount | Optional Metal Frame |
| Size | Custom Available |
The10nm FWHMbandwidth provides selective
transmission around the 485nm target wavelength.
Compared with broad optical filters, the narrow passband helps
optical systems isolate the required spectral region and reduce unwanted background light.
This makes the filter suitable for applications where wavelength accuracy,
spectral selectivity and signal-to-noise performance are important.
The filter providesOD5 blocking, helping suppress
unwanted wavelengths outside the transmission band.
Strong out-of-band attenuation can help reduce back
ground interference and improve the quality of optical signals in detection and imaging systems.
The blocking range can be customized according to the requirements of the optical system.
The filter is manufactured using an optical glass
substrate with a precision multilayer optical coating.
The coating structure is designed to provide:
Different substrate and coating configurations can be discussed
according to the application and wavelength requirements.
For customers requiring easier system integration,
the 485nm optical filter can be supplied with a metal mounting frame.
The mounted configuration can provide:
Round, square and other custom configurations are available.
As an optical filter manufacturer, we can provide customized
solutions according to customer requirements.
Customization options include:
Customers can provide their requiredwavelength, bandwidth,
size and quantityfor quotation and technical evaluation.
The 485nm narrow bandpass filter can be used for selective wavelength
detection in fluorescence imaging systems, helping isolate
the required optical signal from unwanted background light.
Its narrow spectral transmission and OD5 blocking make it suitable
for optical detection and imaging instruments used in biomedical applications.
The filter can help machine vision systems select a specific
wavelength range and reduce unwanted ambient or broadband light.
For optical sensors and analytical instruments, narrow spectral
filtering can improve wavelength selectivity and help enhance detection performance.
The filter can be integrated into spectroscopic, photometric and
other optical analysis systems where selective wavelength transmission is required.
Precise 485nm Transmission
Designed around a 485nm center wavelength for selective optical transmission.
10nm Narrow Bandwidth
The 10nm FWHM provides a relatively narrow
spectral passband for wavelength-selective applications.
OD5 Blocking
Strong out-of-band suppression helps reduce unwanted optical background.
Multilayer Optical Coating
Advanced coating technology provides stable optical filtering performance.
Optional Metal Mount
Mounted versions simplify installation and integration into optical systems.
Custom Manufacturing
Wavelength, bandwidth, size, shape and mounting configurations can be customized.
The standard center wavelength is485nm.
The standard bandwidth is10nm FWHM.
OD5 represents an optical density of 5, corresponding to strong
attenuation of unwanted wavelengths outside the passband.
Ametal mounting frame is available as an optional configuration.
Please confirm your mounting requirements when requesting a quotation.
Yes. Round, square and custom dimensions are available.
Yes. Other center wavelengths and bandwidths can be customized according to the application.
Yes. The blocking range can be designed according to the customer's optical system requirements.
Yes. OEM and ODM optical filter solutions are available for different optical instruments and systems.
