The 650nm 5mW Red Cross Laser Moduleis a compact red cross-line laser
solution designed for alignment, positioning, measurement and equipment integration.
The module provides a visible650nm red cross laser beam with an optical output power of 5mW.
An integratedAPC (Automatic Power Control) circuithelps maintain stable laser output during operation.
The standard version operates from2.8–5.2VDC, with an operating current of less than35mA.
ADC female connector cable approximately 1 meter longis supplied as standard,
while alternative cable configurations are available for different equipment requirements.
The 650nm wavelength produces a visible red cross-line pattern suitable for alignment and positioning applications.
The module provides a5mW red laser outputfor applications requiring a compact visible cross laser source.
The standard module uses anAPC circuitfor automatic power control.
TTL control can be customizedaccording to system requirements.
The laser module operates at2.8–5.2VDC, making it suitable for integration into a variety of electronic and optical systems.
The standard configuration includes aDC female connector cable approximately 1 meter long.
Optional cable configurations include:
The specified continuous operating life ismore than 10,000 hours,
supporting long-term equipment integration.
| Parameter | Specification |
|---|---|
| Wavelength | 650nm |
| Optical Output Power | 5mW |
| Beam Pattern | Cross |
| Laser Color | Red |
| Circuit | APC |
| TTL Control | Custom Available |
| Operating Voltage | 2.8–5.2VDC |
| Operating Current | <35mA |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Service Life | >10,000 Hours |
| Standard Cable | DC Female Connector |
| Cable Length | Approx. 1m |
| Optional Cable | Red/Black, Shielded, Terminal Wire |
| Safety Class | Class IIIA |
| Package | 1 × Laser Module |
The 650nm red cross laser module can be integrated into:
The cross-line pattern provides a convenient visual reference for
applications requiring two intersecting laser lines.
Control & Cable Options
The standard version uses anAPC control circuitand DC female connector cable.
For customized equipment integration, we can provide:
Please provide your required control method and connector specification when requesting a quotation.
OEM & ODM Customization
We support customized red laser module solutions for OEM and ODM projects.
Customization can include:
Send us your required specifications or drawings for engineering review and quotation.
Why Choose This Red Cross Laser Module?
10,000 hours specified service life
The standard wavelength is650nm.
The optical output power is5mW.
It produces ared cross / cross-line beam pattern.
Yes. The standard version uses anAPC circuit.
Yes.TTL control can be customizedaccording to customer requirements.
The operating voltage is2.8–5.2VDC.
The operating current isless than 35mA.
The standard configuration includes aDC female connector cable approximately 1 meter long.
Yes. Red/black wire, shielded cable, terminal wire and other cable configurations are available.
The specified continuous operating life ismore than 10,000 hours.
The supplied specification identifies this product asClass IIIA.
Appropriate laser safety measures should be followed according to the actual installation and applicable regulations.
