The650nm 5mW Red Dot Laser Moduleis a compact red laser solution designed for applications requiring a small, stable and visible laser source.
With an8×17mm all-metal aircraft aluminum housing, this mini laser module is suitable for equipment where installation space is limited. The red laser output provides a visible dot or oval-shaped spot, while the focus can be configured asfixed focus or adjustable focusaccording to the application.
The module operates from2.8–5.2V DCwith a working current below35mAand uses anAPC circuitfor stable laser operation. TTL control can also be customized for applications requiring external modulation.
The miniature8×17mm laser moduleis designed for compact electronic and optical equipment.
Its small cylindrical housing makes it easy to integrate into devices where installation space is limited while maintaining a practical visible red laser output.
The all-metal aluminum housing also provides mechanical protection for the internal laser components.
The laser spot can be supplied with either:
For adjustable-focus versions, the focal position can be optimized according to the customer's required working distance.
This allows the module to be configured for different positioning, alignment and measurement applications.
The module uses anAPC (Automatic Power Control) circuitto help maintain stable laser output during operation.
For applications requiring electronic modulation,TTL control can be customizedaccording to customer requirements.
This makes the module suitable for integration into OEM equipment and automated optical systems.
The 650nm red laser produces a visibledot or oval-shaped spot.
The output spot can be focused according to the required operating distance. In indoor environments, the effective visible range can reachup to approximately 100 meters, depending on ambient lighting and viewing conditions.
| Item | Specification |
|---|---|
| Wavelength | 650nm ±10nm |
| Output Power | <5mW |
| Laser Color | Red |
| Spot Shape | Dot / Oval |
| Focus | Fixed / Adjustable |
| Housing Size | 8×17mm |
| Housing Material | Aircraft Aluminum |
| Circuit | APC |
| TTL | Customizable |
| Working Voltage | 2.8–5.2V DC |
| Working Current | <35mA |
| Operating Temperature | -10°C to +40°C |
| Storage Temperature | -20°C to +70°C |
| Service Life | >10,000 Hours |
| Safety Class | Class IIIA |
| Tail Wire | Red & Black, approx. 15cm |
Visible red laser dots can be used as a reference point for equipment positioning and alignment.
Compact dimensions and low operating current make the module suitable for integration into industrial equipment.
The visible laser spot can be used as an optical reference in measurement and inspection systems.
The module can serve as a compact visible laser source for sensing and detection equipment.
The small 8×17mm housing is convenient for electronic prototypes and customized laser devices.
The module can be integrated into optical instruments and equipment requiring a compact red laser source.
We provideOEM and ODM customizationfor different application requirements.
Available customization options include:
Send us your required wavelength, power, size and working distance for a customized laser module solution.
Each laser module can be tested according to customer specifications before shipment.
Typical quality checks include:
The laser module is designed for a service life ofmore than 10,000 hoursunder specified operating conditions.
Standard Package:
A1-meter DC female plug wirecan be supplied when ordered with the corresponding power adapter configuration.
The standard wavelength is650nm ±10nm. Other wavelengths can be customized.
The standard output isless than 5mW. Other output powers are available upon request.
Yes. The module can be supplied withfixed focus or adjustable focus.
The compact housing size is8×17mm.
The working voltage is2.8–5.2V DC.
Yes.TTL control can be customizedaccording to the customer's application.
Yes. We support OEM/ODM customization for wavelength, power, focus, housing, wiring, connector and control circuit.
The specified service life ismore than 10,000 hoursunder suitable operating conditions.
