530nm 1W Green Laser Module, 12V Ground Beacon & Positioning Laser
The 530nm 1W Green Laser Moduleis a high-power green laser source
designed for ground beacon, positioning, optical indication and other
applications requiring a bright visible green laser spot.
The module provides a1W green laser outputwith12V DC inputand supports
continuous operation. Its φ40×45mm housing provides a compact structure
for integration into dedicated laser equipment and outdoor positioning systems.
The green laser module is also suitable for specializedbird deterrent and
bird control systems, subject to applicable local regulations and safe operating requirements.
| Parameter | Specification |
|---|---|
| Product Type | High Power Green Laser Module |
| Model | EL-SD5201W-40×45 |
| Item Number | LK-SD231W |
| Wavelength | 530nm |
| Rated Power | 1W |
| Exit Pupil Power | 1W |
| Input Voltage | 12V DC |
| Working Current | 1600mA |
| Working Mode | Continuous |
| Light Type | Green Light Spot |
| Installation | Insert |
| Dimensions | φ40 × 45mm |
| Fan | Dimensions exclude fan |
| Cable Length | 50cm |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +85°C |
| Line Width | ≤1.5 |
| Unit Weight | 0.5kg |
| Customization | Available |
The module uses a530nm visible green laser sourcewith a rated output of1W.
The high-power green output provides a bright visible spot for
suitable positioning, beacon and specialized optical applications.
The laser module is designed for12V DC operationand a specified working current of approximately1600mA.
Its continuous operating mode makes it suitable for equipment designed
for sustained laser output. Appropriate heat management and the supplied cooling
configuration should be considered when integrating the module into a system.
With dimensions of approximatelyφ40×45mm excluding the fan,
the module can be integrated into dedicated beacon and positioning equipment.
The 50cm cable simplifies electrical connection during equipment assembly.
Green laser technology can be incorporated into specializedbird deterrent and
bird control systemswhere visible laser movement or projection is used as part of the overall system design.
Actual bird-deterrent effectiveness depends on the target species,
environment, system configuration and operating conditions.
Users should comply with applicable laser-safety, aviation, wildlife and local regulations.
The 530nm 1W green laser module can be considered for:
We support customized green laser modules for OEM applications.
Depending on the project requirements, customization may include:
Please provide the required wavelength, power, voltage, working mode,
housing size and quantity for engineering evaluation.
1W rated output provides a strong visible green laser source for suitable applications.
Designed for 12V DC-powered laser equipment.
Suitable for systems requiring continuous laser output when appropriate thermal management is provided.
Can be integrated into positioning, beacon, optical indication and specialized bird-deterrent systems.
The specified wavelength is530nm.
The rated output power is1W.
The module uses12V DC input.
Yes. The specified working mode iscontinuous.
The specified luminous form is agreen laser spot.
The main housing dimensions areφ40×45mm, excluding the fan.
The specified working current is1600mA.
It can be incorporated into specialized bird-deterrent systems.
Actual system performance depends on application conditions,
and users must follow applicable laser-safety, wildlife and local regulations.
Yes. We support OEM/ODM customization of wavelength, power, housing,
voltage, cable, beam parameters and other mechanical or electrical specifications.
