The RGB 500mW Full-Color Stage Animation Laser Moduleis a compact semiconductor laser source designed for stage lighting, bars, KTV venues, parties, entertainment systems and laser animation equipment.
By combining650nm red, 520nm green and 450nm blue wavelengths, the module provides RGB full-color laser output for line, pattern and animation projection when integrated with a suitable scanning and control system.
With approximately500mW total optical output, fine-spot beam characteristics, continuous operation and a 12V driver board, this module is suitable for OEM stage-lighting and entertainment laser systems.
| Parameter | Specification |
|---|---|
| Product Type | RGB Full-Color Stage Laser Module |
| Model | LK-RGB-T-500MW |
| Order No. | EL-RGB-T-500MW |
| Light Source Type | Semiconductor Laser |
| Laser Colors | Red / Green / Blue |
| Red Wavelength | 650nm |
| Green Wavelength | 520nm |
| Blue Wavelength | 450nm |
| Total Output Power | Approx. 500mW |
| Beam / Spot Type | Fine Spot |
| Working Mode | Continuous Wave |
| Input Voltage | DC 12V |
| Driver Board | Included |
| Standard Dimensions | Approx. 100×40mm |
| Alternative Dimensions | Approx. 62×40mm |
| Wire Length | Approx. 15cm |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +85°C |
| Service Life | >8,000 Hours |
| Unit Weight | Approx. 0.5kg |
The module integrates three visible laser wavelengths:
Through external RGB control and scanning optics, these three channels can be mixed to generate multiple colors for stage lighting and animation projection.
The exact color balance depends on the output power distribution of the individual RGB channels and the external control system.
Compared with coarse-spot RGB modules, this model uses afine-spot configurationthat is better suited for applications requiring cleaner projected lines and animation graphics.
Typical benefits include:
The module provides approximately500mW total RGB optical output.
This output level makes it suitable for compact entertainment laser systems requiring visible multi-color projection while maintaining a relatively small module size.
The individual red, green and blue channel powers should be confirmed for applications requiring precise color balance or calibrated RGB mixing.
Standard configuration:
Custom cable and driver configurations can be evaluated for OEM projects.
The module is available in compact mechanical formats around:
Final dimensions should be confirmed according to the specific optical and driver configuration.
The compact structure is suitable for integration into:
Photex Laser provides RGB 500mW full-color laser modules for stage lighting, laser animation, bars, KTV venues and customized OEM entertainment systems.
