The 405nm 60mW Blue-Violet Star Pattern Laser Moduleis a compact semiconductor laser source designed for decorative projection, entertainment lighting, automotive ambient lighting and customized optical-effect applications.
Featuring a miniatureØ6×10mm copper housing, the module projects blue-violet special patterns such asstars, snow-like effects and butterfly-style decorative patterns, depending on the selected optical element.
The standard version operates at405nmwith approximately60mW optical outputand a5V input. Its compact structure makes it suitable for OEM integration into space-limited decorative and entertainment devices.
| Parameter | Specification |
|---|---|
| Product Type | Blue-Violet Special Pattern Laser Module |
| Model | LK-S4505-P6 |
| Item Number | LK-S45051-P6 |
| Wavelength | 405nm |
| Output Power | Approx. 60mW |
| Laser Color | Blue-Violet |
| Beam Pattern | Star / Snow / Butterfly Decorative Pattern |
| Standard Size | Ø6×10mm |
| Housing Material | Copper |
| Installation Method | Insert Type |
| Input Voltage | DC 5V |
| Working Current | 70–90mA |
| Rated Current | Approx. 70mA |
| Working Mode | Continuous Wave |
| Operating Temperature | -10°C to +35°C |
| Storage Temperature | -30°C to +70°C |
| PCB / Driver | No Integrated Drive Circuit |
| Package Weight | Approx. 0.001–0.002kg |
| Custom Pattern | Available |
The module uses a405nm blue-violet semiconductor laser source, producing a distinctive short-wavelength visible-light effect.
Compared with conventional red or green laser modules, 405nm provides a more violet-toned appearance that is especially suitable for decorative and special visual-effect applications.
Depending on the selected optical element, the module can produce several special effects, including:
The exact pattern geometry can be customized according to project requirements.
The miniatureØ6×10mmhousing makes the module suitable for applications with strict space limitations.
Typical benefits include:
Standard electrical specifications:
The supplied specification indicatesno integrated drive circuit, so the final electrical configuration should be matched carefully to the external power and control system.
Photex Laser provides 405nm blue-violet special-pattern laser modules for decorative lighting, automotive ambient effects, stage entertainment and customized OEM optical applications.
