650nm 100mW Red Circle Laser Module

The650nm 100mW Red Circle Laser Moduleis a high-power visible red laser

source designed to generate a clear and stablecircular laser patternfor

alignment, positioning, measurement and industrial equipment.

Unlike conventional dot or line laser modules,

the circular laser configuration provides a continuous circular reference

that can be used in applications requiring360° visual positioning or circular alignment.

The module can be customized according to different

application requirements, including optical configuration,

housing dimensions, operating voltage, cable and connector.

Key Features

• 650nm visible red laser
• 100mW output power
• Circular / ring laser pattern
• Clear and visible red laser output
• Compact module design
• Suitable for industrial equipment integration
• Optical configuration can be customized
• Housing size can be customized
• Cable and connector customization available
• TTL control available as an option
• OEM / ODM service available

Product Specifications

Circular Laser Pattern

The650nm red circle laser moduleis designed to project a

circular laser pattern rather than a conventional laser dot or straight line.

The circular beam can provide a visual reference around a target area,

making it suitable for applications wherecircular positioning, centering or alignmentis required.

The optical configuration can be optimized according to

the customer's required working distance, circle diameter and application environment.

650nm 100mW High-Power Red Laser

With a100mW output power, this module provides a strong

visible red laser output suitable for applications requiring a more noticeable laser pattern.

The 650nm wavelength offers good visibility for many indoor and industrial applications.

For OEM projects, the wavelength and output power

can be customized according to the customer's application and system requirements.

Compact Laser Module for Equipment Integration

The laser module can be integrated into different types of equipment and optical systems.

The housing, mounting dimensions, cable length and

connector can be customized to match the customer's mechanical and electrical design.

This makes the module suitable forprototype development,

equipment integration and volume OEM production.

Applications

Circular Alignment

Used as a circular reference for optical and mechanical alignment.

Positioning

The circular laser pattern can provide a visible reference for positioning systems.

Measurement

Suitable for measurement and inspection equipment requiring a circular optical reference.

Industrial Equipment

Can be integrated into industrial machinery and specialized equipment.

Optical Instruments

Suitable for optical instruments and systems requiring a visible circular laser source.

Centering Applications

The ring-shaped laser pattern can be used for centering and target positioning applications.

OEM & ODM Customization

We provideOEM and ODM laser module solutionsfor different industrial and optical applications.

Customization options include:

• Wavelength
• Output power
• Circle diameter
• Working distance
• Optical lens
• Beam angle
• Module diameter
• Module length
• Housing
• Operating voltage
• Cable length
• Connector
• TTL control
• Label
• Packaging

Customers can provide atechnical drawing, existing sample, optical requirements or application details.

Our engineering team can evaluate the requirements and recommend a suitable configuration.

Why Choose Our 650nm Circle Laser Module?

High Visible Output

The100mW red laser outputprovides a strong visible circular laser pattern.

Circular Beam

The ring-shaped beam is suitable for circular alignment, positioning and centering applications.

Flexible Optical Design

Optical parameters can be customized according to working distance and required circle size.

OEM Customization

Mechanical and electrical specifications can be customized for equipment integration.

Factory Direct Manufacturing

Suitable for prototypes, small-batch orders and volume OEM projects.

FAQ

What wavelength is this circle laser module?

The standard wavelength is650nm, producing a visible red laser.

What is the output power?

The standard configuration is100mW.

What type of beam does it produce?

The module produces acircular / ring-shaped laser pattern.

What is a red circle laser module used for?

It can be used forcircular alignment, positioning, centering, measurement and industrial equipment.

Can the circle diameter be customized?

Yes. The optical configuration can be customized according to the required working distance and circle diameter.

Can the housing size be customized?

Yes. Module dimensions and housing configurations can be customized for OEM applications.

Can you customize the wavelength and power?

Yes. Different wavelengths and output powers can be evaluated according to application requirements.

Can TTL control be added?

Yes. TTL control can be offered as an optional customization.

Can you manufacture according to our drawing?

Yes. Customers can provide atechnical drawing, existing sample or detailed specificationsfor engineering evaluation.
