Photex Laser offers8mm Collimated Laser Modules in red, green, blue and violet wavelengths
for industrial alignment, optical testing and OEM applications.
Featuring adjustable collimation, coated glass optics and a compact
Ø16 × 81mm aluminum housing, these modules deliver circular, low-divergence laser beams.
8mm Round Beam:Uniform circular laser spot.
Multiple Wavelengths:405–660nm options.
External Adjustment:Adjustable beam collimation.
Low Divergence:Precision parallel beam design.
Compact Housing:Ø16 × 81mm aluminum body.
OEM / ODM:Custom power, beam size and voltage.
| Parameter | Specification |
|---|---|
| Wavelength | 400–1100nm Custom |
| Output Power | Up to 10W (Custom) |
| Beam Diameter | 8mm Standard |
| Beam Profile | Circular / Round Dot |
| Beam Divergence | 0.02mrad (Target) |
| Housing Size | Ø16 × 81mm |
| Operating Voltage | DC 3V / 5V / 12V / 24V |
| Optical Lens | Coated Glass Optics |
| Customization | OEM / ODM Available |
| Color | Wavelength | Power |
|---|---|---|
| Violet | 402–405nm | 5mW–3.5W |
| Blue | 450–455nm | 80mW–6W |
| Cyan | 488nm | 60mW |
| Green | 505–525nm | 5mW–1.8W |
| Red | 635–660nm | 5mW–2.2W |
Specifications depend on configuration. Beam divergence requires verification.
Industrial Laser Alignment
Optical Testing & Measurement
Machine Vision Systems
OEM Laser Equipment
Custom Laser Projection
Wavelength & Output Power
Beam Diameter & Divergence
Housing Size & Voltage
Cable Length & Accessories
Precision Collimated Beam Design
Multiple Wavelength & Power Options
Compact Aluminum Housing
Custom Manufacturing Support
Professional Technical Service
Looking for a reliableCollimated Laser Module Manufacturer?
ContactPhotex Laserfor samples, specifications and OEM solutions.
Send us your wavelength, power, beam diameter and quantity for our best quotation.
