Red dot laser modules are one of the most widely used laser positioning
solutions in industrial equipment, optical instruments and automated systems.
By projecting a bright and concentrated red laser spot, they provide a clear
visual reference for positioning, alignment, inspection and targeting applications.
Photex Laser offers customizedred dot laser moduleswith different wavelengths,
output powers, housing sizes, voltages and focus options for various industrial requirements.
A red dot laser module is a compact laser device that projects a visible red laser spot onto a target surface.
Common wavelengths include:
Among them,650nm red dot laser modulesare widely used because
of their stable performance, good visibility and cost-effectiveness.
Compared with line or cross laser modules, a dot laser module is
particularly suitable for applications requiring a precise single-point reference.
Red dot laser modules are frequently used in industrial positioning systems.
The projected red laser spot can indicate:
This allows operators to quickly identify the required working location and improve positioning efficiency.
In machinery and production equipment, a red dot laser
can provide a simple and intuitive alignment reference.
Typical applications include:
The compact size of the laser module also makes it easy to integrate into industrial machines and instruments.
Red dot laser modules can be combined with cameras and sensors in machine vision systems.
The laser spot can assist with:
Depending on the working environment, the laser wavelength,
power and spot size can be customized to match the imaging system.
Red dot laser modules are also suitable for visual aiming and target indication applications.
A bright laser spot allows users to quickly identify a target or reference position,
making the module useful for optical instruments, detection equipment and alignment systems.
In automated production lines, red dot laser modules
can be integrated into robotic systems, positioning devices and inspection equipment.
Typical applications include:
Photex Laser provides red dot laser modules in different compact housing sizes to meet various installation requirements.
Available customization options include:
Wavelength:635nm, 650nm and other red wavelengths
Output Power:Different power levels available
Housing Size:Miniature and industrial housings
Focus:Fixed focus or adjustable focus
Spot Size:Custom laser spot diameter
Operating Voltage:Customized voltage options
Cable & Connector:Customized cable length and connector
Control:Continuous operation or optional TTL control
Photex Laser focuses on customized laser module solutions for industrial applications.
Our red dot laser modules are designed for:
We can provide laser module solutions according to your required wavelength,
optical power, spot size, working distance, housing dimensions and electrical interface.
Whether you need a miniature red dot laser for optical instruments
or a higher-power laser module for industrial positioning,
Photex Laser can provide customized solutions according to your application.
Contact us for specifications, samples and OEM/ODM laser module solutions.
