Custom Red & Green Laser Projection | Industrial Positioning | OEM/ODM Manufacturer
The Photex Laser Graduated Cross Line Laser Module is designed for precision positioning,
industrial alignment, and customized laser pattern projection.
Featuring a crosshair laser pattern with graduation markings,
this module provides a clear visual reference for equipment alignment,
workpiece positioning, and optical system integration.
Available in red and green laser options, it supports customized projection patterns,
optical configurations, working voltages, and module dimensions.
Whether you need a standard laser generator or a customized optical solution,
Photex Laser offers manufacturing support based on your technical requirements.
1. Graduated Crosshair Projection
Projects a cross-shaped laser pattern with scale markings for visual alignment and positioning.
Customized graduation spacing and patterns are available upon request.
2. Red & Green Laser Options
Red 635–665nm and green 505–535nm configurations are available
for different optical requirements and operating environments.
3. Precision Optical Performance
Optical designs support line accuracy specifications up to ≤40″,
depending on the selected configuration and working conditions.
4. Custom Laser Output
Output power, projection angle, working voltage, and optical design
can be evaluated according to the customer's application.
5. Industrial Integration
Compact module designs support integration into positioning equipment,
manufacturing systems, optical instruments, and automated production machinery.
6. OEM & ODM Customization
Custom laser patterns, housing dimensions, wiring, and optical components are available based on technical drawings.
Machine Positioning
Visual reference for workpiece placement and machine setup.
Assembly Alignment
Crosshair guidance for repeatable component positioning.
Automation Systems
Custom projection patterns for equipment integration.
Optical Instruments
Customized visual references for optical testing and alignment.
Photex Laser supports flexible laser module customization based on project requirements.
|
Custom Item |
Available Options |
|---|---|
|
Laser Wavelength |
Red / Green |
|
Projection Pattern |
Graduated Cross / Cross / Line |
|
Graduation Spacing |
According to Drawing |
|
Projection Distance |
Application Specific |
|
Optical Output |
Customized |
|
Projection Angle |
Customized |
|
Housing Dimensions |
Custom Available |
|
Working Voltage |
Customized |
|
Wire & Connector |
OEM Available |
|
Optical Components |
Glass / PMMA Options |
Send us your technical drawing, working distance, and required laser pattern for evaluation.
Factory-Direct Supply – Competitive pricing for OEM projects and volume orders.
Custom Optical Solutions – Laser pattern and module customization according to your requirements.
Quality Control – Product inspection and optical performance verification according to agreed specifications.
Flexible Orders – Sample evaluation and bulk order inquiries are welcome.
Technical Support – Assistance with wavelength, output power, projection distance, and optical pattern selection.
Q1: Can you customize the graduated crosshair pattern?
Yes. Please provide the graduation spacing, pattern drawing, and projection distance for technical evaluation.
Q2: Do you offer both red and green laser modules?
Yes. Red and green laser configurations are available according to the selected module.
Q3: Can the projection angle and laser power be customized?
Yes. Available options depend on the optical design and operating requirements.
Looking for a reliable graduated cross line laser module manufacturer?
Contact Photex Laser with your required wavelength,
laser power, projection distance, scale pattern, quantity, and technical drawings.
We will evaluate your requirements and provide a customized manufacturing quotation.
Contact Photex Laser for product specifications, OEM customization and bulk quotations.
