  • 8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring
  • 8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring
  • 8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring
  • 8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring
8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring

8x30mm 520nm 10mW Green Line Laser Module External Focus Lock Ring

  • Product Item : 8X30NM520NM 10MW
  • Category: Line Laser module
  • Size :8x30mm
  • Material: aviation aluminum (all-metal casing)
  • Surface treatment/Black color
  • Output wavelength:520nm ± 10nm(Other wavelengths can be customized,)
  • INQUIRY   EMAIL
Focusing method : External focusing band locking ring
Circuit control: APC circuit
Working voltage: 2.7-4.2VDC
Working current: I<180mA
Operating temperature:-10° C to +50 ° C
Storage temperature: -20℃ to +70℃
Service life: Continuous output/usage > 10,000 hours

Tail wire: 26# red and black electronic wire,

approximately 15cm long (photographed together

 with the power adapter, it comes with a 1-meter-long DC female plug wire)

Safety level: CLASS IIIA
Package content: One laser

Applications: Industrial Laser Positioning,

Sighting Devices, Laser Flashlights, Instruments & Equipment,

Medical Devices (Healthcare Equipment), Military Use,

 Anti-Counterfeiting & Security, Stage Lighting, Tools, USB Drives,

Mobile Phones, Presentation Clickers, Temperature

(Distance) Measuring Instruments, Laser Levels, Line Lasers, Spirit Levels,

Electronic Hobbyists, Indoor & Outdoor Decoration, etc.
